Filling Packing Line Custom Electronic Combination Multihead Weigher

The material is conveyed from a material conveyor to the multi-head scale's material hopper. lnside the multi-head scale's material hopper, the vibration from the main vibrator ensures the uniform discharge of material from the main vibrating plate. This material then enters the linear vibrating plate and isdistrilbuted to various linear vibrating plates. The vibration of the linear vibrators causes the material to be discharged from each line's vibrating tray and enter the feeding hopper for storage.

Get a Quote Contact us +86-17685858859

Core Advantages

Why choose us?

01.

PROVEN EXPERTISE IN PRECISION WEIGHING

With years of focus on aquatic and food processing industries, we deliver mature, field-tested sorting solutions trusted by thousands of processing plants . Our deep understanding of your production challenges ensures we solve real pain points, not just sell equipment.
02.

MAXIMIZE YIELD & PROFIT

High-precision grading eliminates under/overweight losses, ensuring every product meets market standards and captures optimal pricing.
03.

SLASH LABOR COSTS

Replace manual sorting with automated, 24/7 operation, cutting labor expenses by up to 60% while reducing human error.
04.

ENSURE COMPLIANCE & QUALITY

Food-safe design and traceable data help you meet strict export and hygiene standards, building trust with global buyers.

Technical Specifications

Model	OYDE-ZH14-2.5	OYDE-ZH16-2.5	OYDE-ZH20-2.5	OYDE-ZH14-5	OYDE-ZH16-5	OYDE-ZH20-5
Weighing Range	20-1000g			1000-10000g
Accuracy	±0.1-1.5g			±0.5-10g
Hopper Capacity	2500ml			5000ml
Weighing Speed	30-60b/min	40-80b/min	60-100b/min	10-60b/min
Equipment Weight	500KG	550KG	750KG	850kg	900kg	1000kg
Options	Dimple Plate/Timing Hopper/Printer/Reject Device			Dimple Plate/Timing Hopper/Printer/Reject Device
Weighing sensor	HBM
Driving System	Step Motor
Power Requirement	220V/1500W/ 50/60Hz /10A
Equipment Material	Stainless Steel 304
Packaging Material	Solid wood fumigation
